Passive Filter

Dufew Electric Passive Filter is designed for industrial power systems affected by harmonic currents from VFDs, converters, rectifiers, and other nonlinear loads. By combining filter reactors, capacitors, and non-inductive damping resistors in a tuned LC circuit, it provides a low-impedance path for selected harmonic frequencies and helps reduce harmonic current circulation in the power network.

Nonlinear loads generated during AC-DC conversion and power electronic switching can contribute to transformer overheating, increased cable losses, reduced power factor, additional stress on electrical equipment, and unstable power quality. Depending on the system conditions, the filtering configuration can be designed to address characteristic harmonics such as the 5th, 7th, 11th, and higher-order components.

The system helps reduce harmonic current distortion, improve power factor, limit harmonic-related losses, and support stable electrical operation. Compared with active harmonic compensation systems, passive filtering uses a relatively simple electrical structure without complex control circuits, making it suitable for continuous operation in industrial applications with predictable harmonic characteristics.

How the LC Filtering System Works?

Tuned Resonance Circuit

The reactor and capacitor form a tuned LC branch designed for specific harmonic frequencies.

When harmonic currents reach the designed frequency range, the filtering branch provides a lower impedance path than the power network, allowing harmonic currents to be absorbed effectively.

This design provides:

- Targeted harmonic reduction

- Lower current waveform distortion

- Improved electrical stability

- Continuous industrial operation capability

Damping and Protection Design

The integrated non-inductive resistor controls resonance characteristics and improves circuit stability.

The damping structure helps:

- Prevent excessive resonance amplification

- Limit abnormal harmonic current

- Improve capacitor reliability

- Extend system service life

Key Advantages

1. Simple Passive Structure

The passive design operates without DSP controllers or additional electronic compensation modules, resulting in a straightforward electrical structure with fewer control components, lower maintenance requirements, and good adaptability to industrial operating environments.

2. Improved Power Quality

By reducing harmonic current circulation, the system can help limit transformer and cable losses, reduce temperature rise, improve power factor, and support more stable operation of connected electrical equipment.

3. Designed for Industrial Applications

Dufew applies engineering considerations to magnetic components, reactor and capacitor matching, thermal performance, and electrical safety. The resulting configuration is suitable for continuous operation in industrial power systems with relatively predictable harmonic characteristics.

Typical Applications

Dufew Passive Filter is suitable for industrial systems with relatively stable harmonic characteristics.

Typical applications include manufacturing plants, metallurgy and chemical processing facilities, mining equipment, textile machinery, paper production lines, port machinery, and injection molding systems where nonlinear loads and harmonic currents need to be managed.

Customized Design Capability

Different electrical systems require different filtering parameters.

Dufew provides engineering support based on:

- Harmonic measurement data

- Load characteristics

- System voltage level

- Installation environment

- Required THDi performance

Customized solutions are available for different industrial power quality requirements.

Selection Guide

Selecting a suitable filtering solution requires evaluation of:

Dufew provides customized recommendations based on harmonic measurement data, system parameters, and project requirements.

Manufacturing Capability & Quality Assurance

Dufew Electric specializes in industrial power electronics manufacturing, providing passive filters, reactors, braking resistors, transformers, and customized electrical solutions for industrial applications. Its engineering work covers harmonic analysis, electrical parameter matching, and power quality requirements, supporting application-specific product design and manufacturing.

Key manufacturing capabilities include magnetic core processing, precision reactor winding, capacitor and resistor matching, electrical parameter verification, and thermal performance testing. Depending on the product configuration, quality inspection may include:

- Insulation resistance testing
- Dielectric withstand testing
- Resonance parameter verification
- Temperature rise testing
- Electrical parameter inspection
- Final appearance inspection

Quality documentation can include ISO quality management certification, product testing reports, and electrical performance verification records according to the applicable product and project requirements.

Dufew Electric supports OEM manufacturing, customized electrical design, engineering cooperation, and project-based power quality solutions.

Technical Specifications

Passive Filter vs Active Harmonic Filter

FAQ

Q1: What components are used in a Passive Filter?

A Passive Filter consists of reactors, capacitors, and damping resistors that form a tuned LC circuit. These components provide a low-impedance path for selected harmonic currents and help improve power quality.

Q2: How should the suitable model be selected?

Model selection depends on rated voltage, operating current, harmonic source, harmonic spectrum, THDi requirements, system configuration, and installation conditions.

Q3: Is this solution suitable for all harmonic conditions?

Passive filtering is generally suitable for systems with stable harmonic characteristics. Applications with rapidly changing harmonic loads may require alternative compensation solutions.

Q4: Can Dufew customize filtering solutions?

Yes. Dufew provides customized solutions based on voltage level, current capacity, harmonic characteristics, installation requirements, and project conditions.
